Introduction

The idea for a sunrise simulation came to life during the winter of 2023 after we moved to Germany. If you've experienced winter here, you know — nights are long, dark, and utterly committed to making weekend mornings an exercise in sheer willpower. More often than not, it’s that obnoxious alarm that shocks you awake, leaving you to wonder why you bothered setting it in the first place.

I stumbled across alarm clocks designed to wake you up with a blend of light and sound. The concept of gradually increasing brightness sounded dreamy — until I tried it and discovered these lights barely rivaled a dim nightlight. That was when the idea of building my own sunrise simulator came to me. Not only would it brighten our mornings, but it could also serve as a little project to survive the hostile German winter.

After some research, I came to the conclusion that Raspberry Pi would be the best option to kickstart my project. I had never worked with a single-board computer before, neither had I ever configured a hardwired LED setup. But hey, stepping out of the scripting comfort zone is half the fun I thought!

Hardware Setup

The hardware configuration seemed straightforward at first glance: the Raspberry Pi has a set of pins that allow it to send and receive signals. Naturally, one might think all it takes is to connect the red, green, and blue channels to the Raspberry Pi’s pins and let the Python code control the LED.

However, as with most things in life, there’s more to it. First, it’s important to understand how the LED strip works. Unlike light bulbs that can be dimmed by regulating current, LEDs are quickly turned on and off. The longer the LED is off, the dimmer it appears. This effect is called Pulse Width Modulation (PWM). Therefore, it’s essential to find the pins on the Raspberry Pi that natively support PWM for this setup.

Once you have that figured out, the next question is how much power the Raspberry Pi's pins can supply, and whether that’s enough for a power-hungry LED strip. The answer according to most sources is "no". This is where the setup enters a completely different realm beyond simple scripting and wiring. We now need MOSFETs, a breadboard, and other components. Fortunately, there are experts who have already figured out what parts are needed, how to calculate their properties, and even compiled shopping lists with links to purchase them.

For everything hardware-related, I recommend checking out an online source like David Ordnung’s blog, which covers how to set up an LED strip with a Raspberry Pi.

Python Code

# setup environment
import pigpio
import time

# setup GPIO pins
red_pin = 13
green_pin = 19
blue_pin = 26

# maximum RGB brightness
max_brightness = 255

# set colors
dark_orange = (255, 69, 0)  # RGB values for dark orange
daylight = (255, 255, 255)  # RGB values for daylight

# simulation times in seconds
total_transition_time = 1800  # 30 minutes
full_brightness_time = 3600  # 1 hour

def setup():
    pi = pigpio.pi()
    if not pi.connected:
        raise RuntimeError("Failed to connect to pigpio daemon")

        # initialize PWM cycles to 0% brightness
        pi.set_PWM_dutycycle(red_pin, 0)
        pi.set_PWM_dutycycle(green_pin, 0)
        pi.set_PWM_dutycycle(blue_pin, 0)

        return pi

def interpolate_color(start_color, end_color, progress):
    """Calculate intermediate color based on progress (0 to 1)."""
    return (
        int(start_color[0] + (end_color[0] - start_color[0]) * progress),
        int(start_color[1] + (end_color[1] - start_color[1]) * progress),
        int(start_color[2] + (end_color[2] - start_color[2]) * progress)
    )

def simulate_light_transition(pi):
    # gradually transition from dark orange to daylight over 30 minutes
    start_time = time.time()
    while time.time() - start_time < total_transition_time:
        elapsed_time = time.time() - start_time
        progress = elapsed_time / total_transition_time

        # calculate RGB values based on progress
        red, green, blue = interpolate_color(dark_orange, daylight, progress)

        # gradually Transition from 0 to 100% brightness
        pi.set_PWM_dutycycle(red_pin, max(0, min(max_brightness, red)))
        pi.set_PWM_dutycycle(green_pin, max(0, min(max_brightness, green)))
        pi.set_PWM_dutycycle(blue_pin, max(0, min(max_brightness, blue)))

        time.sleep(1)

def main():
    pi = setup()

    try:
        # simulate light transition
        simulate_light_transition(pi)

        # keep light on at full brightness for 1 hour
        pi.set_PWM_dutycycle(red_pin, daylight[0])
        pi.set_PWM_dutycycle(green_pin, daylight[1])
        pi.set_PWM_dutycycle(blue_pin, daylight[2])
        time.sleep(full_brightness_time)

    finally:
        # cleanup
        pi.set_PWM_dutycycle(red_pin, 0)
        pi.set_PWM_dutycycle(green_pin, 0)
        pi.set_PWM_dutycycle(blue_pin, 0)
        pi.stop()

if __name__ == "__main__":
    main()



Raspberry Setup

With the working script, you now only need to tell your Raspberry Pi to run the script on your dream schedule, e.g., every Saturday and Sunday at 10 AM. I use cron to achieve this:

crontab -e
0 10 * * 6,7 /usr/bin/python3 /scripts/sunrise_simulation.py


Disclaimer

If you choose to follow my instructions, use my code for the Raspberry Pi sunrise simulation project, or follow linked content and please do so at your own risk. I am not responsible for any damages to equipment, injury, or any other negative outcomes that may result from the use of code and information provided, or external content. It is your responsibility to ensure proper safety precautions, adhere to electrical and hardware guidelines, and understand the risks involved when working with electronics and coding projects.
